功能描述：
clc;
clear;
close all;
warning off;
global testbler;
RelayUser_Scheduled=[];
testbler=[];
SS = [];
%%%%%%%%%%%%%%%%%%%%%%%%%%%%^^^^ 系統參數 ^^^^%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
dSimulationTime = 2; % 仿真TTI數200
nNumOfRuns = 1; % 撒點次數5
dKmCiteToCiteDistance = 0.5; % 基站間距離 km
dCellRadius = dKmCiteToCiteDistance/sqrt(3); % 小區半徑
dKmMinDistance = 0.035; % 用戶和基站間的最小距離 km
nNumofCell = 19; % 系統中的小區數19
nNumofSector = nNumofCell*3; % 系統中的扇區數
nNumofUserPerSector = 5; % 每個扇區中的用戶數10
nTotalNumofUser = nNumofSector*nNumofUserPerSector; % 系統內總用戶數
dwBsTransmitPower = 40; % 基站總發送功率 W (46dBm)
dwRNTransmitPower = 2; % 中繼總發送功率 W (33dBm)
dwMsTransmitPower = 0.25; % 移動臺發送功率 W
ddBBSNoisefigure = 5; % 基站熱噪聲指數 dB
ddBUENoisefigure = 7; % 移動臺熱噪聲指數 dB
ddBRNNoisefigure = 6; % 中繼熱噪聲指數 dB
ddBmThermalNoise = -174; % 熱噪聲指數 dBm/Hz
dHzSubcarrierBandWidth = 15000; % 子載波帶寬 Hz
dMHzCarrierFrequency = 2000; % 載波頻率 MHz
dUserVelocity = 0; % 用戶移動速度 km/h
ddBShadowFadingStdBS2UE = 8; % 陰影衰落標準差BS2UE dB
ddBShadowFadingStdBS2RN = 3.4; % 陰影衰落標準差BS2RN dB (16j中為3.4dB,LTE-A中為6dB）
ddBShadowFadingStdRN2UE = 10; % 陰影衰落標準差RN2UE dB
dShadowFadowCorrelation = 0.5; % 陰影衰落相關系數
ddBBSTransmitAntennaGain = 14; % BS發送天線增益 dB
ddBRNCoverageAntennaGain = 5; % RN覆蓋天線增益 dB
ddBRNDonorAntennaGain = 23; % RN施主天線增益 dB
ddBUEReceiveAntennaGain = 0; % UE接收天線增益 dB
ddBPenetrationLoss2UE = 20; % 到UE的穿透損耗 dB
ddBPenetrationLoss2RN = 0; % 到RN的穿透損耗 dB
dwPerSubcarrierWhiteNoise = 10^((ddBmThermalNoise-30)/10)*dHzSubcarrierBandWidth; % 每個子載波上的白噪聲 W
dBER_Target = 10^(-1); % 目標誤比特率
dSNR_gap = -log(5*dBER_Target)/1.5; % Tao
%%%%%%%%%%%%%%**** OFDM Parameters ****%%%%%%%%%%%%%%%
dLenthofSubframe = 0.001; % 子幀時長 s
nNumofSubcarrier = 600 ; % 系統可用子載波數600
nNumofRB = 60; % 系統可用資源塊數24
granularity = 10; %subcarrier sampling granularity
nSCRNumPerRBinDefination = nNumofSubcarrier/nNumofRB; % 實際每個資源塊上的子載波數
nNumofSubcarrierPerRB = nNumofSubcarrier/nNumofRB/granularity; % 粒度簡化后每個資源塊上的子載波數
nFFTSize = 1024; % FFT大小
pdusize = nSCRNumPerRBinDefination*14*(dLenthofSubframe/2)/0.001; %symbols per PDU(每個RB的子載波數*一個時隙的符號數，規定1ms為14個符號)ofRB
%%%%%%%%%%%%%%**** 中繼配置參數 ****%%%%%%%%%%%%%%%%%%
nNumofRelayPerCell = 6; % 每個小區的Relay數
nNumofRelayPerSector = 2; % 每個扇區的Relay數
nTotalNumofRelay = nNumofSector*nNumofRelayPerSector; % 系統內總中繼數
nFRF = 3; % 每小區內中繼間頻率復用因子
%%%%%%%%%%%%%%%**** MIMO參數 ****%%%%%%%%%%%%%%%%%
nTxAntenna = 1;
nRxAntenna = 1;
%%%%%%%%%%%%%%%%**** 業務參數 ****%%%%%%%%%%%%%%%%%%%%
MaxBSBufferSizeInPacket = 200; % BS中每個用戶的數據包的最大數量
nTrafficClass = 4; % 不同速率需求的業務的種類
dRateRequired1 = 2*10^6; % 業務1的速率需求bps
% dRateRequired2 = 6.4*10^4; % 業務2的速率需求bps
% dRateRequired3 = 6.4*10^4; % 業務3的速率需求bps
% dRateRequired4 = 6.4*10^4; % 業務4的速率需求bps
% dRateRequiredofUser = repmat([dRateRequired1,dRateRequired2,dRateRequired3,dRateRequired4],1,nTotalNumofUser/nTrafficClass); % 各用戶的速率需求
dRateRequiredofUser = dRateRequired1.*ones(1,nTotalNumofUser); % 各用戶的速率需求
IDofUserReachedRate=[]; % 達到速率需求的用戶的編號（全局）
Rate=[]; % 達到速率需求的用戶的速率
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%% OVER %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
nSchedulerFlag = 1; %RR調度
%%%%%%%%%%%%%%%%%%%%%%%%%^^^^ 定義系統變量 ^^^^%%%%%%%%%%%%%%%%%%%%%%%%%%%%
%%%%%%%%%%%%%%%%%%%%%%%**** Wrap Around給小區編號 ****%%%%%%%%%%%%%%%%%%%%%%
Cell_Wrap_Num = [
[0,1,2,3,4,5,6,7,8,9,10,11,12,13,14,15,16,17,18];[1,8,9,2,0,6,7,13,12,16,15,10,11,3,4,5,17,18,14];
[2,9,10,11,3,0,1,8,16,15,14,18,17,12,13,4,5,6,7];[3,2,11,12,13,4,0,1,9,10,18,17,16,8,7,14,15,5,6];
[4,0,3,13,14,15,5,6,1,2,11,12,8,7,18,10,9,16,17];[5,6,0,4,15,16,17,18,7,1,2,3,13,14,10,9,8,12,11];
[6,7,1,0,5,17,18,14,13,8,9,2,3,4,15,16,12,11,10];[7,13,8,1,6,18,14,4,3,12,16,9,2,0,5,17,11,10,15];
[8,12,16,9,1,7,13,3,11,17,5,15,10,2,0,6,18,14,4];[9,16,15,10,2,1,8,12,17,5,4,14,18,11,3,0,6,7,13];
[10,15,14,18,11,2,9,16,5,4,13,7,6,17,12,3,0,1,8];[11,10,18,17,12,3,2,9,15,14,7,6,5,16,8,13,4,0,1];
[12,11,17,16,8,13,3,2,10,18,6,5,15,9,1,7,14,4,0];[13,3,12,8,7,14,4,0,2,11,17,16,9,1,6,18,10,15,5];
[14,4,13,7,18,10,15,5,0,3,12,8,1,6,17,11,2,9,16];[15,5,4,14,10,9,16,17,6,0,3,13,7,18,11,2,1,8,12];
[16,17,5,15,9,8,12,11,18,6,0,4,14,10,2,1,7,13,3];[17,18,6,5,16,12,11,10,14,7,1,0,4,15,9,8,13,3,2];
[18,14,7,6,17,11,10,15,4,13,8,1,0,5,16,12,3,2,9]
];
%%%%%%%%%%%%%%%%%%%**** 讀取語音數據文件 ****%%%%%%%%%%%%%%%%%%%%%%
SCFid=fopen('SrcConfigFile_VTMix6AT','r');
SrcCnfgrFile=fscanf(SCFid,'%d',[5,171])';
fclose(SCFid);
aSFid=fopen('audio Source File.bin','r');
status=fseek(aSFid,16,'bof');
nVoIPSourceFile=fscanf(aSFid,'%d',[3,58019])';
fclose(aSFid);
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%% OVER %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
第一：從理論上詳細討論了的能耗，吞吐量以及能效等性能指標的公式推導，并從理論上分析得到了基于節點休眠算法的中繼蜂窩網具有較佳的性能指標。
第二：通過MATLAB建立的仿真模型，對普通蜂窩網，中繼蜂窩網以及基于節點休眠算法的中繼蜂窩網三種模型進行了性能仿真，并分析了仿真結果，得到了基于節點休眠算法的中繼蜂窩網具有最佳的性能指標。
